WIX Spin-On Fuel/Water Separator Filter
Part # 33970 | Line Code: WIX
brandNameImage
brandNameImage

$97.99
$97.99
error
Not Fitted

Product Details
expand_less
Burst Pressure 200
Collapsed Pressure Rating 100
Outer Diameter Top 4.230
Heavy Duty Supplier Yes
Micron Rating 9.00
Media Material Cellulose
Thread Size 1-14
Inner Diameter Top Closed
Duty Type HD
Drain 1
Drain Cock 1
Micron 9.00
Capacity(grams) 70.00
FilterArea(sq ines) 682
MediaType Cellulose
Style Spin-On Fuel/Water Separator F
CollapsePressure 100
California Proposition 65 WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Class HW
Height 5.790
BurstPressure 200
BetaRatio 2/75=9/40
Part Terminology Fuel Water Separator Filter

Features & Benefits
expand_more
WIX HD Fuel Water separator filters feature an enhanced cellulose silicone treated media or a new generation full synthetic media that provides excellent contaminant holding capacity for super clean fuel and water removal. High strength, corrosion resistant cans, center tubes, and end caps with superior sealing components ensure a leak resistant, long lasting, high performing fuel water separator filter. Some models feature a water drain port with a threaded plug or patented self-venting drain valve for efficient water purging as needed.

Application Summary
expand_more

New Holland, Freightliner - if you wish to add a plastic bowl to the 33970, can add bowl part # WS10003 - remove the drain from the bottom of the filter, install the bowl, then install the drain to the bottom of the bowl.
