| Thermal Or Centrifugal | A - 5" & 6" Import |
| Terminal Type | N/A |
| Clutch Maximum Diameter | 6.3 |
| Distance From Clutch To Mounting Flange | 1.45 |
| Use Type | Standard |
| Rotation | REV |
| Mounting Type | HEX |
| Mounting Hole Quantity | 3 |
| Color | Raw Aluminum in Color |
| Bolt Hole Quantity | 3 |
| Grade Type | Standard |
| Material | Aluminum |
| Clutch Type | A - 5" & 6" Import |
| Heavy Duty Supplier | Yes |
| O.E. Replacement? | Yes |
| New or Reman | New |
| Meets / Exceeds OEM? | Yes |
| Mount Hole Qty | 3 |
| SDS Required | No (135233618) |
| Performance Rated? | Yes |
| Bolt Quantity | 3 |
| Mounting Hardware? | Not Included |
| Type | Thermal |
| Electronic Clutch? | No |
| Mount Type | HEX |
| Description | Fan Clutches |
| Bolt Thread | M6 x 1.0 Hole |
| Overall Dia. MM | 160 |
| Duty Rating | Standard |
| Fan Mount Dia. MM | 134.9 |
| Style | Standard Duty |
| Drawing Type | A |
| Fan Bolt Circle MM | 147.1 |
| Fan Mount Dia. IN | 5.31 |
| Pilot Depth IN | 0.58 |
| Pilot Depth MM | 14.7 |
| Overall Height MM | 55.1 |
| Fan Mount Height MM | 36.8 |
| Overall Dia. IN | 6.3 |
| Fan Bolt Circle IN | 5.79 |
| Dia. IN | 6.3 |
| Mount Dia. MM | 32 |
| Mount Dia. IN | 1.25 |
| Mounting Hardware Included | No |
| Overall Height IN | 2.17 |
| Part Terminology | Engine Cooling Fan Clutch |
